Technical specifications

Show

Woods

  • Body: Flamed Maple top, Mahogany resonant plate and Alder
  • Neck: 5 pieces laminate, Maple/Wenge
  • Width at the nut: 46 mm
  • Width at the 24.fret: 78 mm
  • Fingerboard radius: 16"/407 mm
  • Fingerboard: African Ebony
  • Positional marks on the fingerboard: Pearl
  • Positional marks at the side of the fingerboard: Pearl
  • Nut: Ebony
  • Body finish: Natural, High Glossy
  • Neck finish: Natural, High Glossy

Hardware

  • Bridge: Hipshot A Style, black
  • String spacing at the bridge: 18 mm
  • Tuning machines: Hipshot Ultralite, black
  • Frets: 24x Jumbo 2.9 mm wide
  • control knobs: Metal knobs with oval head, black
  • Strap pins: Schaller Strap Locks, black
  • Strings: Elixir Nickel Roundwound 0.045-0.130
  • Weight: 4.45 kg

Electronics

  • Neck pickup: EMG 40 DC-X
  • Bridge pickup: EMG 40 DC-X
  • Electronics: Active/Passive electronics AV Basses, 3 band
  • Wiring: 1x volume, 1x blend, 1x bass, 1x mid, 1x treble
  • Battery: 1x 9V
  • Ouput jack: Stereo 6.3 mm
