Technical specifications

Show

Woods

  • Body: Buckeye Burl top & Ash
  • Neck: 9 pieces, Hard Maple/Bubinga
  • Fingerboard: AAA Indian Rosewood
  • Positional marks on the fretboard: Pearl blocks + custom graphics Signature, Pearl
  • Positional marks at the side of the fretboard: Pearl
  • Nut: Ebony
  • Width at the nut: 56 mm
  • Width at he 24.fret: 90 mm
  • Fingerboard radius: 16"/407 mm
  • Body finish: Natural, High Glossy
  • Neck finish: Natural, High Glossy

Hardware

  • Bridge: Single rail string saddles, gold
  • String spacing at the bridge: 18 mm
  • Tuning machines: Gotoh GB707, gold
  • Frets: 24x Jumbo 2.9 mm wide
  • Control knobs: Metal knobs with oval head, gold
  • Strap pins: Schaller strap locks, gold
  • Strings: Ernie Ball 0.045-0.130
  • Scale: 34" (864 mm)
  • Weight: 5.3 Kg

Electronics

  • Neck pickup: Aguilar Super Single Coil
  • Bridge pickup: Aguilar Super Single Coil
  • Electronics: Active/Passive electronics Aguilar OBP-3
  • Wiring: 1x volume with push/pull for switching off active electronics, 1x blend, 1x bass, 1x mids with switch to 400/800 Hz frequency, 1x treble
  • Battery: 1x 9V
  • Output jack: Stereo 6.3 mm
